special valves (connected by internal and external thread, welding and flange)

Find the intersection point of the flow rate V L/min and the pressure loss ∆P MPa (usually 0.02 MPa to 0.03 MPa) on the pressure loss chart for the strainer. The nominal size line above the intersection point represents the required nominal size. When the fluid to be used is different from water in viscosity and specific gravity: Take any of each nominal size from pressure loss chart (for water) in each product, and calculate the pressure loss at that point using the expression shown below. Draw a line of the same gradient as water’s nominal size line. Then, find the required nominal size as When the filter element and the filter screen are different: Pressure loss seldom changes even if our perforated sheet and filter screen are replaced. However, fine ones and coarse ones are different in the state and progression of clogging. Set a higher safety factor for a finer one. How to calculate the pressure loss of a strainer: Find the intersection point of the nominal size line and the flow rate on the chart. The ∆P value at the intersection point is the pressure loss of the strainer.

We had attend to FLOWTECH CHINA (SHANGHAI ) 2021 exhibition from 2nd June to 4th June 2021. Our booth number is 4.1 H365.

From December 17th to 19th 2024, we participated in a major exhibition in Dubai, UAE, at booth S2G206. The event was a great opportunity to promote our products and expand our presence in the global market.
